4SD16 Pump End

Applications
For water supply from boreholes
For domestic, garden and irrigation applications
Operating conditions
Maximum fluid temperature up to +35°C
Maximum sand content: 0.25%
4SD Minimum well diameter: 4” (100mm)
Wet end
Outlet Size : 1&1/4” (32mm)
Equip With Single phase: 220V – 240V/50Hz 4” motor
Three phase: 380V – 415V/50Hz 4” motor
Equip with standard or digital automatic control box
Pumps are designed by casing stressed
NEMA Dimension standards
Curve tolerance according to ISO 9906
Warranty: 1 year
(According to our general sales conditions)
